EXPLODED VIEW PARTS LIST
Local No. PART No.
DESCRIPTIONS
112 6334V21004B CPT, A51QDX992X 0G[V] 0G[H] SSDI BARE
6334V21009A CPT, A51QDJ420X 01 16KHZ BARE AK MASK (RT-21FB55VY.LFLLEU8), LGEMT
6334V21013B CPT, A51QDJ420X 000MGB 16KHZ LPDSG (RT-21FB55VE.LMLLSB8)
6335V21019A CPT ASSEMBLY, A51QDJ420X 01MDDR M(+0.30G) 0G (FOR SHAHAB)
6335V21019F CPT ASSEMBLY, A51QDJ420X 01LDDR L(+0.50G) 0G LG-PHILIPS DISPLAYS AK CPT ITC
120 120-C77G SPEAKER,FULLRANGE C122P02K1459 8 OHM 10/15W 130 57*117
120-C77M SPEAKER,FULLRANGE C122P02K1459 ESTEC 8 OHM 10/15W 130DB 57*117MM
121 4810V00088B BRACKET, SPEAKER CE-29K30 PP
150 150-D02T COIL,DEGAUSSING,AL 21” 56T 12 OHM
150-D02X COIL,DEGAUSSING CU 21” 60TURN 12 OHM D02N (NYLON)
6140VC2007E COIL,DEGAUSSING AL 44TURN 11OHM 0.60PIE 2500MM 21”
153 6150V-1014H DY(DEFLECTION YOKE), 6150V-1019C 21” LPDBJ S/S FREE CPT
6150V-1014J DY(DEFLECTION YOKE), 6150Z-1227A 21” LG SLIM
6150V-1014N DY(DEFLECTION YOKE), 6150Z-1228A 21” LPDBJ GREEN TYPE LPDSG AK CPT
6150V-1019C DY(DEFLECTION YOKE), DIF-2192AA(NF5) 21” SAMSUNG
170 170-A01N CPT EARTH, 21” 64T 2LUG 1P HSG CL-21Q20ET(PC-99DA)
174 174-009E POWER CORD, POWER(W/HOLD,HOUSING,L=200,4.0
6410VEH001B POWER CORD, 174-009E CHAUS VDE/SEMKO 2410MM 2P
6410VEH001J POWER CORD, EL-207 VDE/SEMKO 2100MM HOUSING L1=200 BLACK
300 3091V00474M CABINET ASSEMBLY, RT-21FB55VQ STEREO MC049B SY->SET
3091V00474Q CABINET ASSEMBLY, RT-21FB55V STEREO MC049B SY->CKD
3091V00484M CABINET ASSEMBLY, RT-21FB55V STEREO MC049B MT-CKD
3091V00484N CABINET ASSEMBLY, RT-21FB55RX STEREO MC049B MT-SET
3091V00484U CABINET ASSEMBLY, RT-21FB57V STEREO MC049B SY-MT
3091V00484V CABINET ASSEMBLY, RT-21FB57V STEREO MC049B MT LOCAL
3091V00694B CABINET ASSEMBLY, RT-21FB55VE STEREO E_PHONE MC049B LGEEG TOOL
3091V00B25B CABINET ASSEMBLY, RF-21FB55VQ.KMLLKS2 CKD STEREO MC019A
3091V00B25S CABINET ASSEMBLY, RT-21FB55VQ STEREO E_PHONE MC049B SHAHAB CKD
310 5020V00704A BUTTON, CONTROL ABS, HF-380 6KEY (RT-21FB55VQ.KMLLKS2)
5020V00704B BUTTON, CONTROL RT-21FB55RQ ABS, HF-380 6KEY .”
5020V00738B BUTTON, CONTROL RT-21FB55VQ ABS, HF-380 6KEY SY LOCAL
5020V00749C BUTTON, CONTROL RT-21FB55V ABS, HF-380 6KEY 117A MT LOCAL
5020V00938B BUTTON, CONTROL RT-21FB55VE ABS 6KEY LGEEG
320 320-062E SPRING, KNOB
320-062H SPRING, COIL
330 5020V00703A BUTTON, POWER ABS, HF-380 1KEY(RT-21FB55VQ.KMLLKS2)
5020V00703C BUTTON, POWER RT-21FB55RQ ABS, HF-380 1KEY
5020V00737C BUTTON, POWER RT-21FB55VQ ABS, HF-380 1KEY SY LOCAL
5020V00748D BUTTON, POWER RT-21FB55V ABS, HF-380 1KEY 84B MT LOCAL
5020V00939B BUTTON, POWER RT-21FB55VE ABS LGEEG
400 3809V00323B BACK COVER ASSEMBLY, RT-21FB55VE.LMLLSB8 DVD(1PHONE) SY-SET
3809V00323J BACK COVER ASSEMBLY, RT-21FB55VQ.LTLLSC8 (407AF) 1PHONE SY-CASAS
3809V00323U BACK COVER ASSEMBLY, RT-21FB55VE DVD(1PHONE) 8G068(407AF)SY-SET
3809V00323V BACK COVER ASSEMBLY, RT-21FB55VE DVD(1PHONE) 8G068(407AF)SY-C/SKD
3809V00333F BACK COVER ASSEMBLY, RT-21FB55V DVD(1PHONE) 8G068 MT-CKD
3809V00333G BACK COVER ASSEMBLY, RT-21FB55RX DVD(1PHONE) 8G068 MT-SET
3809V00333K BACK COVER ASSEMBLY, RT-21FB55R DVD(1PHONE) 8G068 SY-MT
3809V00477D BACK COVER ASSEMBLY, RT-21FB55VE(EG SET) DVD(1PHONE) MC049B
3809V00A74B BACK COVER ASSEMBL, RF-21FB50VE CKD 1PHONE
520 6871VMM882N PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB57V.PTSLTM7 M/I
6871VMM895D PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55VQ.KMLLKS2(PPL)
6871VMM895R PWB(PCB) ASSEMBLY,MAIN MC-049B RT-21FB56VY.LFLLEU8
6871VMM895S PWB(PCB) ASSEMBLY,MAIN MC-049B RT-21FB55VY.LFLLEU8
6871VMM895U PWB(PCB) ASSEMBLY,MAIN MC-049B RT-21FB55VW.LFLLEU8
6871VMM896G PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55VQ.LTLLSC8
6871VMA896U PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55VE.LMLLSB8
6871VMM897D PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55RX.LTLLTM7 M/I
6871VMM897G PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55VX.LTLLTM7 M/I
6871VMM897L PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55R.LTLLTM7 M/I
6871VMM901A PWB(PCB) ASSEMBLY,MAIN MC-049B RT-21FB55VQ.KMLLKS8 IRAN
6871VMM923K PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55VE.LDLLSR8 M
6871VMM923U PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55V.LFLLSBU M/I
6871VMM947M PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB57R.NTMLLET M.I
6871VMMJ01N PWB(PCB) ASSEMBLY,MAIN M.I MC049B RT-21FB55M QDRLLBK
6871VMMT79M PWB(PCB) ASSEMBLY,MAIN MC049B RT-21FB55V.LTSLVV8 LGEVN PH
6871VMMU15G PWB(PCB) ASSEMBLY,MAIN MC-049B RT-21FB57V.LTLLTM7 M/I
570 6871VSML08A PWB(PCB) ASSEMBLY,SUB PIP MC049B
700 0IGL120104A IC,LG SEMICONDUCTOR CDS SENSOR MODULE(P1201-04)
913 332-057B SCREW,DRAWING ASSY,HEXAGON HEAD
943 1PTF0403116 SCREW TAP TITE(P),TRUSS HEAD + D4.0 L16.0 MSWR3/FZB
The components identified by mark is
critical for safety.
Replace only with part number specified.
