- 21 -
07
0A
08
06
00
00
00
00
00
00
00
00
00
00
00
01
39
0F
00
00
01
00
00
02
00
00
07
00
00
R-Y R
R-Y B
G-Y R
G-Y B
UP-BL
LO-BL
EW-DC
UP-UP
LO-UP
UP-UG
LO-UG
UC-PO
VB-SW
CLP-S
NON-I
AFC-M
L-BLK
R-BLK
CLP-P
CLP-G
HB-SW
ZOOSW
JMPSW
VFREQ
VCOMP
HCOMP
AKBTM
BLK-O
AKBOF
Menu Description
R-Y axis + (R-Y) component setting
R-Y axis + (B-Y) component setting
G-Y axis + (R-Y) component setting
G-Y axis + (B-Y) component setting
VBLK position control for top of picture, when VBLK_SW = 1
VBLK position control for bottom of picture, when VBLK_SW=1
EW_DRV signal DC level down switch
Horizontal pin distortion compensation position adjustment for extreme
top edge of picture
Horizontal pin distortion compensation position adjustment for extreme
bottom edge of picture
Horizontal pin distortion compensation amount adjustment for extreme
bottom edge of picture
Horizontal pin distortion compensation amount adjustment for extreme
top edge of picture
Horizontal pin distortion compensation polarity setting for extreme
top/bottom edge of picture
VBLK period mode setting switch
Internal clamp pulse start phase setting
Interlace/progressive mode switch
AFC loop gain control
HBLK width control for left side of picture when HBLK_SW =1
HBLK width control for right side of picture when HBLK_SW =1
Internal clamp pulse phase control
Switch for gating internal clamp pulse with input HSYNC
HBLK width control ON/OFF switch during 4:3 software full display
mode on a 16:9 CRT
Zoom mode ON/OFF switch for 16:9 CRT
Reference pulse jump mode ON/OFF switch
Vertical frequency setting
High voltage fluctuation compensation amount setting for vertical
picture size
High voltage fluctuation compensation amount setting for horizontal
picture size
AKB Bch reference pulse timing setting
Blanking ON/OFF SW when AKBOFF=1
Automatic cut-off/manual cut-off setting
Range PAL
4.Picture adjustment data (IC:CXA21802)
