LG RT-44A85 Series User Manual

- 22 -
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
1
0
0
0
1
INPUT
MAT-O
VFREQ
SELS1
SELS2
FIX-S
V-TC
H-WID
HSEPS
HD-DC
HYSW
HS-MA
MACRO
SELDU
CLK-S
G-SEL
CBGAI
CRGAI
YGAIN
HFREQ
Menu Description
Selects the four systems of inputs IN1 to IN4
Selects the type of matrix conversion
Selects the frequency of the dummy sync output to SELV_OUT(pin23)
Selects the type of the signal input to IN1_H/L1(pin36) and IN1_V/L2(pin37)
Selects the type of the signal input to IN1_H/L1(pin44) and IN1_V/L2(pin45)
Switches the sync identification circuit operating mode
Sets the V sync separation time constant
Sets the SELH_OUT (pin22) output pulse width
Sets the sync separation method. (Valid for YG_IN(Pin16) input)
Sets the H sync separation time constant of the YG_IN (Pin16) input
Switches the signal output to YG_OUT (Pin 15)
Sets whether or not to add H-sync within V-sync at SELH_OUT(Pin22)
Switch for eliminating the macrovision signal of the 525P signal at SELH_OUT (Pin22). This is
valid only when HFREQ =1
This Switch selects whether to output the sync separated signal or the dummy Sync to
SELH_OUT (Pin22) and SELV_OUT(Pin23)
This switch selects the clock for the sync counter
This switch selects the gain or mute of the signals output to SELCR_OUT (Pin25),
SELCB_OUT(Pin26) and SELY_OUT (pin27)
SELCB_OUT(Pin26) gain control
SELCR_OUT(Pin25) gain control
SELY_OUT(Pin27) gain control
Selects the frequency of the dummy sync output to SELH_OUT(Pin22)
Range PAL
5.CXA2151Q adjustment item
