17
INSTALLATION
ENGLISH
2
Insert one side of the tray first, then the other.
Push the tray until it slides completely in.
3
To detach, pull one side out then the other.
• If the tray collects water, detach it and empty
the water. After emptying it, reassemble the
tray.
• Do not operate the appliance without installing
the drip tray. Doing so could lead to water
damage caused by leaking.
Installing cap covers
1
Line up the nubs on the cap cover with the
holes in the top corner of the cabinet and then
snap the cap cover into place.
2
Repeat with the remaining cap cover on the
other corner.
Installing hinge covers
1
Open the appliance door.
2
Snap the hinge cover onto the upper hinge
assembly with the bent edge on the far side
from the hinge.
3
Repeat with the remaining hinge cover on the
lower hinge assembly.
