3
b If you are using an external device (ex. Set-top box, Blu-ray player, game console, etc.), connect it to the sound
bar or to the TV via an HDMI cable.
c If you purchased the rear speakers and wireless receiver separately, connect the rear speakers to the wireless
receiver via a speaker cable. When connecting the rear speakers to the wireless receiver, connect the black
striped cable to the negative terminal of each speaker and the remaining cable to the positive terminal of
each speaker.
d Connect to power in the following order: wireless subwoofer [ wireless receiver [ sound bar. Then, turn on
the sound bar. When the connection is automatically established with the sound bar, the LEDs on the wireless
subwoofer and the wireless receiver will light up in green. ([ See “Connecting the Product” on page 6.)
e Using the product with your TV ([ See “Connecting with an
Optical Cable”, “Connecting with an HDMI Cable”, “Connecting
via Bluetooth”, “Connecting an external device via HDMI A” on
page 36, 38, 40, 41.)
A Press the Function button repeatedly until LED1 and LED2 light up white. If you are using an external
device that is connected to HDMI™ IN on the sound bar, press the Function
button repeatedly until LED1
and LED3 light up white.
B On your TV's settings, set the output speaker to [HDMI ARC], [Optical], or [External Speaker].
f Connecting the product to your smartphone via Wi-Fi ([ See
“Connecting with a Smartphone via Wi-Fi” on page 17.)
A Connect your smartphone to Wi-Fi.
B Install the LG Sound Bar app on Google Play or the App Store.
C Run the LG Sound Bar app and follow the instructions.
D The product will connect to your smartphone and you can control the product with LG Sound Bar app.
g Connecting the product to your smartphone via Bluetooth ([
See “Connecting via Bluetooth” on page 45.)
A Tap the Settings button on your smartphone and select Bluetooth. Turn on the Bluetooth function.
( Off > On)
B Press the Bluetooth pair
button. After a moment, LED2 blinks blue.
C Find and tap “LG_Speaker_SC9S_XXXX” or the name you registered on the Google Home app.
D When the product is connected to your smartphone via Bluetooth, all LEDs light up blue.

LG SC9S Specifications

General

Line-in	No
Bluetooth	Yes
Bluetooth codec	SBC, AAC
Bluetooth version	5
Headphone outputs	0
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Subwoofer type	Active subwoofer
Subwoofer sensitivity	85 dB
Subwoofer connectivity	Wireless
Woofer diameter (subwoofer)	7 \
Display type	LED
Certification	Carbon Trust, UL ECV, Eco-Product, Energy Star
Product color	Black
Audio formats supported	AAC, AAC+, LPCM
Consumer Electronics Control (CEC)	SimpLink
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Audio decoders	DTS Digital Surround, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
Equalizer modes	Bass Blast, Bass Blast+
RMS rated power	400 W
Audio output channels	3.1.3 channels
Top speaker RMS power	90 W
Center speaker RMS power	30 W
Front speakers RMS power	60 W
Audio sample rate (24bit)	96 kHz
Center speaker sensitivity	83 dB
Cables included	HDMI
Number of products included	1 pc(s)
Impedance	4 Ω
Number of speakers	9
Soundbar speaker RMS power	180 W
AC input frequency	50 Hz
Soundbar power consumption	37 W
Power consumption (standby)	0.5 W
Power consumption (typical)	75 W
Subwoofer power consumption	38 W
Package type	Box
Package depth	261 mm
Package width	1296 mm
Package height	574 mm
Package weight	22700 g

Weight and Dimensions

Depth	284 mm
Width	1221 mm
Height	47 mm
Soundbar weight	4100 g
Subwoofer depth	313 mm
Subwoofer width	221 mm
Subwoofer height	390 mm
Subwoofer weight	7800 g
