LG SC9S User Manual

6
Installation
Connecting the Product
You can enjoy a richer sound by connecting the sound bar to the wireless subwoofer.
Connecting the wireless subwoofer automatically
After completing installation, the wireless subwoofer will automatically be connected to the sound bar. Connect
the sound bar to the subwoofer in the following order.
a Plug the power cable into the wireless subwoofer.
b Plug the power cable connected to the wireless subwoofer into an outlet.
c Plug the power cable into the AC adapter.
d Connect the AC adapter cable to the DC IN (AC adapter input) terminal on the back of the product.
e Plug the power cable connected to the AC adapter into an outlet.
f When the connection is automatically established, you will see the LED on the wireless subwoofer light up in
green.
Note
• Make sure to use the provided AC adapter. Using other AC adapters may lead to malfunction and will forfeit the
product warranty.
Installation

LG SC9S Specifications

General

Line-in	No
Bluetooth	Yes
Bluetooth codec	SBC, AAC
Bluetooth version	5
Headphone outputs	0
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Subwoofer type	Active subwoofer
Subwoofer sensitivity	85 dB
Subwoofer connectivity	Wireless
Woofer diameter (subwoofer)	7 \
Display type	LED
Certification	Carbon Trust, UL ECV, Eco-Product, Energy Star
Product color	Black
Audio formats supported	AAC, AAC+, LPCM
Consumer Electronics Control (CEC)	SimpLink
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Audio decoders	DTS Digital Surround, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
Equalizer modes	Bass Blast, Bass Blast+
RMS rated power	400 W
Audio output channels	3.1.3 channels
Top speaker RMS power	90 W
Center speaker RMS power	30 W
Front speakers RMS power	60 W
Audio sample rate (24bit)	96 kHz
Center speaker sensitivity	83 dB
Cables included	HDMI
Number of products included	1 pc(s)
Impedance	4 Ω
Number of speakers	9
Soundbar speaker RMS power	180 W
AC input frequency	50 Hz
Soundbar power consumption	37 W
Power consumption (standby)	0.5 W
Power consumption (typical)	75 W
Subwoofer power consumption	38 W
Package type	Box
Package depth	261 mm
Package width	1296 mm
Package height	574 mm
Package weight	22700 g

Weight and Dimensions

Depth	284 mm
Width	1221 mm
Height	47 mm
Soundbar weight	4100 g
Subwoofer depth	313 mm
Subwoofer width	221 mm
Subwoofer height	390 mm
Subwoofer weight	7800 g
