Part 1 General Information
3. Nomenclature
• Global Model Name
3.1 Indoor unit s
3.2 Decoration panel(For ceiling cassette models)
3.3 Outdoor units
A T NH 2 4 3 P L AD
Serial Number
Functions
A : Basic C : Plasma Air Purifier E: Elevation grille
Look : Basic
Chassis Name
Electrical Ratings
6:1
G: 1Ø 220V~240V, 50/60Hz
3: 1Ø 208V~230V, 60Hz
Ø,220V-240V,50Hz 8:3 Ø,380V-415V,50Hz
Capacity code
Model Type
C: Cooling Only H: Heat Pump
R410A Universal Indoor Unit
ATN : Universal Ceiling Cassette Type Indoor Unit
ABN : Universal Ceiling Concealed Duct Type Indoor Unit
AVN : Universal Ceiling & Floor Type Indoor Unit
A U UH 1 8 6A
Serial Number
Electric Standard (Phase, Volts, Freq)
6:1
3: 1Ø 208V~230V, 60Hz
Ø,220V-240V,50Hz 8:3 Ø ,380V-415V,50Hz
Capacity code
Model Type
C : Cooling Only H : Heat Pump W: Inverter Heat Pump
R410A Universal Outdoor Unit
PT- H E A
Functions
A: Basic C:For Indoor Unit with Plasma Air Purifier.
Indoor Unit Chassis
Model Type
C : Cooling Only H : Heat Pump U: Universal
Decoration Panel of Ceiling Cassette Type Indoor Unit
