LG SJ8S Service Manual

Copyright © 2017 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
3-303-29
CN100 (PRIMARY <-> Wireless)
Power MAIN Wireless module SPEC
WL_3V3 3.308 V 3.304 V 3.3 V (3.15 ~ 3.45 V)
CN101 (PRIMARY <-> SECONDARY)
Power MAIN Wireless module SPEC
SMSC_3V3 3.31 V 3.28 V 3.3 V (3.15 ~ 3.45 V)
CN102 (PRIMARY <-> BT)
Power MAIN BT module SPEC
3.3V 3.33 V 3.3 V 3.3 V (3.15 ~ 3.45 V)
3. CONNECTOR VOLTAGE
3-1. PRIMARY UNIT
3-2. SECONDARY UNIT
CN700 (SECONDARY <-> PRIMARY)
Power MAIN Wireless module SPEC
WLS_3V3 3.304 V 3.297 V 3.3 V (3.15 ~ 3.45 V)
CN501 (SECONDARY <-> BT)
Power MAIN BT module SPEC
BT_3V3 3.35 V 3.31 V 3.3 V (3.15 ~ 3.45 V)
