LG SPD7Y User Manual

4
Manually connecting the sound bar to the wireless subwoofer or wireless
receiver ([ See “Connecting the wireless subwoofer manually”, “Manual
connection” on page 8, 10.)
If you see a red LED on the back of the wireless subwoofer or on the front of the wireless receiver, it means
that the sound bar is not connected to the speakers. If this is the case, connect them in the following order.
A Press the Power
button on the sound bar to turn it off.
B Press the PAIRING (Pairing) button on the back of the disconnected wireless subwoofer or wireless
receiver. Check if each LED blinks green.
- If you still see a red LED on the back of the wireless subwoofer, press and hold the button on the
back of the subwoofer again.
C Press the Power
button on the sound bar to turn it on.
D When the connection is established, you will see a green LED light on the back of the wireless
subwoofer or on the front of the wireless receiver light up in green.

LG SPD7Y Specifications

General

Audio decoders	DTS Digital Surround, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	380 W
Audio output channels	3.1.2 channels
Audio Return Channel (ARC)	Yes
Subwoofer sensitivity	85 dB
Subwoofer connectivity	Wireless
Soundbar speaker RMS power	160 W
Wi-Fi	No
HDCP version	2.3
Bluetooth version	4.0
Connectivity technology	Wired & Wireless
Digital audio optical out	1
Product color	Black
TV stand usage	-
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV, WMA
Consumer Electronics Control (CEC)	SimpLink
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Package type	Box
Package depth	441 mm
Package width	988 mm
Package height	225 mm
Package weight	11770 g

Weight and Dimensions

Depth	119 mm
Width	890 mm
Height	65 mm
Soundbar weight	3700 g
Subwoofer depth	290 mm
Subwoofer width	180 mm
Subwoofer height	394 mm
Subwoofer weight	5800 g
