LG SPD7Y User Manual

6
Installation
Connecting the Product
You can enjoy a richer sound by connecting the sound bar to the wireless subwoofer.
Connecting the wireless subwoofer automatically
After completing installation, the wireless subwoofer will automatically be connected to the sound bar. Connect
the sound bar to the subwoofer in the following order.
a Plug the power cable into the wireless subwoofer.
b Plug the power cable connected to the wireless subwoofer into an outlet.
c Plug the power cable into the AC adapter.
d Connect the AC adapter cable to the DC IN (AC adapter input) terminal on the back of the product.
e Plug the power cable connected to the AC adapter into an outlet.
f When the connection is automatically established, you will see the LED on the back of the wireless subwoofer
light up in green.
Note
• Make sure to use the provided AC adapter. Using other AC adapters may lead to malfunction
and will forfeit the product warranty.
Installation

LG SPD7Y Specifications

General

Audio decoders	DTS Digital Surround, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	380 W
Audio output channels	3.1.2 channels
Audio Return Channel (ARC)	Yes
Subwoofer sensitivity	85 dB
Subwoofer connectivity	Wireless
Soundbar speaker RMS power	160 W
Wi-Fi	No
HDCP version	2.3
Bluetooth version	4.0
Connectivity technology	Wired & Wireless
Digital audio optical out	1
Product color	Black
TV stand usage	-
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV, WMA
Consumer Electronics Control (CEC)	SimpLink
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Package type	Box
Package depth	441 mm
Package width	988 mm
Package height	225 mm
Package weight	11770 g

Weight and Dimensions

Depth	119 mm
Width	890 mm
Height	65 mm
Soundbar weight	3700 g
Subwoofer depth	290 mm
Subwoofer width	180 mm
Subwoofer height	394 mm
Subwoofer weight	5800 g
