LG SPD7Y User Manual

41
Mounting the Product to a Wall
a Find the wall bracket installation guide in the product package.
b Align the “TV Bottom Line” on the wall bracket installation guide with the bottom of the TV, and attach it to
the wall.
Align the center of the wall-mounted TV with the part marked “TV Center” in the installation guide.
c With a pen, mark screw holes on the installation guide where the wall brackets will be attached.
d Drill screw holes in the marked positions on the installation guide.
e Remove the wall bracket installation guide from the wall.

LG SPD7Y Specifications

General

Audio decoders	DTS Digital Surround, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	380 W
Audio output channels	3.1.2 channels
Audio Return Channel (ARC)	Yes
Subwoofer sensitivity	85 dB
Subwoofer connectivity	Wireless
Soundbar speaker RMS power	160 W
Wi-Fi	No
HDCP version	2.3
Bluetooth version	4.0
Connectivity technology	Wired & Wireless
Digital audio optical out	1
Product color	Black
TV stand usage	-
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV, WMA
Consumer Electronics Control (CEC)	SimpLink
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Package type	Box
Package depth	441 mm
Package width	988 mm
Package height	225 mm
Package weight	11770 g

Weight and Dimensions

Depth	119 mm
Width	890 mm
Height	65 mm
Soundbar weight	3700 g
Subwoofer depth	290 mm
Subwoofer width	180 mm
Subwoofer height	394 mm
Subwoofer weight	5800 g
