Figure 2-1 (1)
Figure 2-1 (2)
2. HOW TO DISASSEMBLE THE SUBWOOFER
2-1. Rear Panel Assembly
1) Remove the 13 screws.
2) Pull out the Rear Panel Assembly and disconnect the SPK cable.
Rear Panel Assembly
SPK cable
