Appendix 35
Appendix
5
Wireless subwoofer
Power requirements Refer to the main label on the subwoofer.
Power consumption Refer to the main label on the subwoofer.
Type 1 Way 1 Speaker
Impedance 3
Ω
Rated Input Power 100 W RMS
Max. Input Power 200 W RMS
Dimensions (W x H x D) Approx. 171.8 mm x 301.0 mm x 204.0 mm
SPQ4-S (SPQ4-S, S67S3-S)
Wireless receiver
Power consumption Refer to the main label on the wireless receiver.
AC adapter
y
Model : A931-230087W-M21
y
Manufacturer : Dongguan Aohai Technology Co.,Ltd.
y
Input : 100 - 240 V ~ 50/60 Hz
y
Output : 23.0 V
0
0.87 A
Dimensions (W x H x D) Approx. 175.0 mm x 61.0 mm x 175.0 mm
Rear speakers (Each)
Type 1 Way 1 Speaker
Impedance 4
Ω
Rated Input Power 30 W RMS
Max. Input Power 60 W RMS
Dimensions (W x H x D) Approx. 88.4 mm x 120.9 mm x 80.4 mm
y
Actual features, functionality, and other product specications may differ and are subject to change without
notice.
