2) Disassembly of Back Panel, Power
Cord, Inlet Valve & BP Sensor
① Remove two back panel xing screws in the
back side.
② Disassemble the back panel.
③ Disconnect two connectors and disassemble
the power cord.
④ Remove a valve xing screw & disconnect the
leads form the inlet valve.
⑤ Remove the inlet valve.
⑥ Disconnect the leads & the pressure tube from
the BP sensor.
⑦ Remove the BP sensor.
