Basic Adjustments of the Stand
A5
1. Adjust the angle of the panel as follows.
How to adjust the angle of the panel
Tilt Range :
T1710B -> 14˚ to 66˚
T1910B -> 14˚ to 68˚
14˚
66˚(68˚)
The state which the stand
locking handle is released
The state which the stand
locking handle is locked
Do not push the stand with basic
adjustment to the direction of the
panel. The product may fall down
to hurt people, or cause product
disorder or screen damage.
After installing the monitor, adjust the angle as follows.
Basic Adjustment
Push back the panel to the end, and use from the point that it automatically returns.
2. After adjusting the angle of the panel for convenience, lock with the locking
handle to prevent the product from moving.
Panel
Stand
To Next Page
