78 2005 Product Data
8. Performance Data Heating
AS-H1865DM0[S18AHP S50]
Correction Factor for Heating Capacity due to Frost on Heat Exchanger and Defrosting Operation.
The heating capacity in the "Heating Capacity Table" above indicates the actual heating capacity excluding the effect of frost on the heat
exchanger and the defrosting operation. Therefore, use the following factor to calculate the average heating capacity including capacity
reduction by frost on the exchanger and defrosting operation.
Correction Factor
■ Notes :
1. All capacities are net, indoor fan motor heat is deducted.
2. Capacities are based on the following conditions.
Outdoor air : 85%RH. However, the condition on nominal capacity is 7˚CDB/6˚CWB
3. TC=Total heating capacity(Unit : kW)
4. PI=Power Input (Comp.+indoor fan motor+outdoor fan motor) (kW)
TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC PI
16 3.9 1.3 4.6 1.4 5.3 1.6 5.6 1.6 5.9 1.7 6.2 1.7 6.7 1.8 7.4 1.9
18 3.8 1.4 4.5 1.5 5.2 1.6 5.4 1.7 5.7 1.7 6.0 1.8 6.5 1.8 7.2 2.0
20 3.7 1.4 4.3 1.5 5.0 1.7 5.3 1.7 5.5 1.8 5.8 1.8 6.3 1.9 7.0 2.0
22 3.5 1.5 4.2 1.6 4.8 1.7 5.1 1.8 5.3 1.8 5.6 1.9 6.1 2.0 6.7 2.1
24 3.4 1.5 4.0 1.6 4.7 1.8 4.9 1.8 5.1 1.9 5.4 1.9 5.9 2.0 6.5 2.2
Indoor DB
(˚C)
Outdoor WB (˚C)
-10-502461015
AS-H246TKA2[G24AH ST3]
TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC PI
16 4.7 1.8 5.5 2.0 6.3 2.1 6.7 2.2 7.0 2.3 7.4 2.3 8.0 2.4 8.8 2.6
18 4.5 1.8 5.3 2.0 6.1 2.2 6.4 2.3 6.8 2.3 7.1 2.4 7.7 2.5 8.5 2.7
20 4.4 1.9 5.1 2.1 6.0 2.3 6.3 2.3 6.6 2.4 6.9 2.5 7.5 2.6 8.3 2.8
22 4.2 2.0 5.0 2.2 5.7 2.3 6.0 2.4 6.3 2.5 6.7 2.5 7.2 2.7 8.0 2.9
24 4.1 2.0 4.8 2.2 5.5 2.4 5.8 2.5 6.1 2.6 6.4 2.6 7.0 2.7 7.7 2.9
Indoor DB
(˚C)
Outdoor WB (˚C)
-10-502461015
AS-H2465DM0[S24AHP S50]
TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC PI
16 4.7 1.8 5.6 2.0 6.5 2.2 6.8 2.2 7.1 2.3 7.5 2.3 8.1 2.5 9.0 2.6
18 4.6 1.9 5.4 2.1 6.3 2.2 6.6 2.3 6.9 2.4 7.3 2.4 7.9 2.6 8.7 2.7
20 4.5 1.9 5.3 2.1 6.1 2.3 6.4 2.4 6.7 2.5 7.0 2.5 7.7 2.6 8.4 2.8
22 4.3 2.0 5.1 2.2 5.9 2.4 6.2 2.5 6.5 2.5 6.8 2.6 7.4 2.7 8.1 2.9
24 4.2 2.1 4.9 2.3 5.7 2.5 5.9 2.5 6.2 2.6 6.6 2.7 7.1 2.8 7.9 3.0
Indoor DB
(˚C)
Outdoor WB (˚C)
-10-502461015
Outdoor Air Temperature( ˚CWB, RH=85%) -10 -6 -4 -2 0 2 4 6
Correction Factor 0.95 0.95 0.89 0.87 0.87 0.89 0.91 1
