9. Electric Characteristics
21
Single CAC Outdoor Unit
Compact Inverter
Outdoor Unit
Model names
Combined Indoor Unit Unit Power Supply COMP OFM IFM
Model names
No. of
Units
Pha
se
Hz Volts
Voltager
ange
MCA
MFA
(MOP)
MSC RLA kW FLA kW FLA
AUUW18GC0
[UU18WC UL0]
ABNW18GBHC0
[UB18C NH0]
11Ø50
220 -
240
Min.:198
Max.:264
12.6 15 - 10.0 0.043 0.25 0.154 0.80
AUUW24GC0
[UU24WC UE0]
ABNW24GBHC0
[UB24C NH0]
17.9 20 - 15.0 0.085 0.33 0.154 1.10
AUUW30GC0
[UU30WC UE0]
ABNW30GM1A0
[UM30 N14]
18.4 20 - 15.0 0.085 0.33 0.137 0.80
AUUW36GC0
[UU36WC U40]
ABNW36GM2A0
[UM36 N24]
21.2 25 - 17.0 0.124 0.48 0.350 1.14
Note
1. Voltage supplied to the unit terminals should be within the minimum and maximum
range.
2. Maximum allowable voltage unbalance between phase is 2%.
3. MSC means the Max. current during the starting of compressor.
4. MSC and RLA are measured as the compressor only test condition.
5. OFM and IFM are measured as the outdoor unit test condition.
6. Select the wire size based on the MCA.
7. MFA is used to select the circuit breaker and ground fault circuit interrupter, and
recommended circuit breaker type is ELCB(Earth Leakage Circuit Breaker).
MCA : Minimum Circuit Amperes (A)
MFA : Maximum Fuse Amperes (A)
MSC : Maximum Starting Current
RLA : Rated Load Amperes (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
kW : Fan Motor rated output (kW)
FLA : Full Load Amperes (A)
