39
1.
Disassemble the back cover.
2.
Loosen the bolt.
3.
Pull out the Rotor.
4.
Unscrew the 2 screws from the tub bracket.
5.
Loosen the 6 bolts on the stator.
6.
Unplug the 2 connectors from the stator.
1.
Disassemble the damper hinges from the tub
and base.
2.
Separate the dampers.
NOTE
• Once removed, replace the damper pin
with new one.
