7. TROUBLESHOOTING
7-1.BEFORE PERFORMING SERVICE
Be careful of electric shock or disconnecting the parts while troubleshooting.
Voltage of each terminal in 220-240V~ and DC while applying an electric current.
7-2.QC TEST MODE.
Pressing Rinse, and Spin button simultaneously.
Power supply on with pressing upper two button.Then buzzer sound twice.
Press the Start/Pause button as follows.
Press the Start/Pause button more 4 times until stop spinning
7-3.HOW TO KNOW THE WATER LEVEL FREQUENCY
Press the
Rinse and Spin button simultaneously.
ex) 241 : Water level frequency = 241 10
-1
=24.1
The digits means water level frequency (10
-1
)
Pressing number of
Start/Pause button
Checking Point Display Status
None All lamps turn on
1 time Clockwise spin (right) Drum rpm (About 40~50)
2 times Low speed Spin Drum rpm (About 53~65)
3 times High speed Spin Drum rpm (About 140~160)
4 times Inlet valve for prewash operation Water level frequency (25~65)
5 times
Inlet valve for mainwash operation
Water level frequency (25~65)
Hot inlet valve in case of hot water fill
6 times Inlet valve for mainwash operation Water level frequency (25~65)
7 times Counterclockwise spin (left) Drum rpm (About 40~50)
8 times
Heater is in operation for 3 sec.
Water temperature
9 times Draining pump operation Water level frequency
10 times
Auto off operation
