37
2)
Disassembly of Back Panel, Power
Cord, Inlet Valve & BP Sensor
Remove two back panel fixing screws in the
back side.
1
Disassemble the back panel.
2
Disconnect two connectors and disassemble
the power cord.
3
Remove the inlet valve.
5
Remove the BP sensor.
7
Disconnect the leads & the pressure tube from
the BP sensor.
6
Remove a valve fixing screw & disconnect the
leads form the inlet valve.
4
To Next Page
