33
Disconnect the POWER connector and SENSOR
SWITCH ASSEMBLY.
Remove the Protect Cover.
Disconnect the connectors.
Unscrew 1 screw on the back.
Disassemble the Main PWB.
CONNECTOR
PROTECT COVER
MAIN PWB ASSEMBLY
