LG WM2077CW Service Manual

40
Disassemble the back cover.
Remove the bolt.
Pull out the Rotor.
Unscrew the 2 screws from the tub bracket.
Remove the 6 bolts on the stator.
Unplug the 2 connectors from the stator.
Disassemble the damper hinges from the tub
and base.
Separate the dampers.
NOTE
• Once removed, replace the damper pin with
new one.
