LGB 55020 - Page 3

3
to
g
earbox / zum Getriebe
GL1
Function
bn-braun/brown gn-grün/green
U+
Track
U+Front li
g
ht
M2Motor
U+Back li
g
ht
Funktion
ws-weiss/white gb-gelb/yellow
F1 GND
GL2
Gleis
U+ >>> L1 = 24 V / 200mA
U+ >>> L2 = 24 V / 200mA
F1 >>> U+ = 24 V / 300mA
GL1 >>> GL2 = 24 V
M1 >>> M2 = 24 V / 1,5A
L1 Licht vorne
M1 Motor
L2 Licht hinten
F1 = Function output / Funktionsaus
g
an
g
M1 = Motor (yellow) / Motor (
g
elb)
M2 = Motor (
g
reen) / Motor (
g
rün)
GL1 = Track (brown) / Gleis (braun)
GL2 = Track (white) / Gleis (weiss)
L2 = Backli
g
ht / Licht hinten
U+ = Positive (L1, L2) Gemeinsamer (L1,L2)
L1 = Front li
g
ht / Licht vorne
LGB 55020
1
2
