LGB 55021 - Page 14

14
CV Description Range
As set
at the
factory
60
Adjustment factor *
1 = slight, 255 = strong
1 – 255 48
61
Adjustment speed *
0 = fast, 255 = very slow
0 – 255
62
Adjustment strength *
0 = none, 255 = maximum
0 – 255
67 –
94
Freely programmable
Speed level table *
0 – 255
* The values are set to be optimal for LGB motors. We
recommend against making changes.
CV Description Range
As set
at the
factory
1 Address 0 – 22 3
2
Startup voltage
0 = slow, 255 = maximum speed
0 – 255 0
3 Acceleration 0 – 255 3
4 Delay 0 – 255 3
5
After entry of CV6 function value in the
CV to be programmed
5 Max. voltage for the max. speed level 1 – 255 255
6 Register address when programming 4
29
Number of speed levels, direction,
analog and/or digital operation, speed
level table, see extra table
49
Voltage value for F1
32 = locomotive with interface
26 = 19 volt lights
5 = 5 volt lights
1 – 32 32
50
Voltage value for light outputs
compare CV 49
1 – 32 32
51
Button assignments for F1,
see extra table
52
Button assignments for front light(s),
see extra table
53
Button assignments for rear light(s),
see extra table
54
Load monitoring
0 = off, 2 = on
0, 2 2
55 Reset 55
