4
Register Assignment Range Default
CV 1 Switch decoder address 1 - 255 1
CV 2
Programming protection (input “77“ to allow one-time programming of a
single CV)
77
CV 3 Switch setting direction (“0“: normal; “1“: inverse) 0 - 1 0
CV 7
Input „55“ to reset loco address (CV 1 and CV 9) to “1“ During read-out:
software version
CV 8 HManufacturer code, read only 123
CV 9
Switch decoder address Byte 2 (address x 256)
For addresses above 255, byte 1 is programmed in CV 1 and byte 2 in CV 9:
Address = CV 9 x 256 + CV 1 (Not for LGB MTS).
0 - 7 0
No other functions can be programmed. For advanced
applications, we recommend the LGB 55025 MTS
Switch Decoder.
