LifeSpan TR1200iT - Page 9

11
Hardware Included
Item# Part Description Item# Part Description
1 Right Upright Post 5 Console
2 Left Upright Post 6 Right Cup Holder
3 Right Upright Post Cover 7 Left Cup Holder
4 Left Upright Post Cover
Hardware Bag Contents
Item # Qty. Hardware Description
N/A 1 6mm Allen Wrench
N/A 1 5mm Allen Wrench with Phillips Screw Driver
9 4 M10 x 45L Bolt -
(Upright Post Attachment)
10 4 M10 Washer - (Upright Post Attachment)
11 2 M8 x 70L Bolt - (Handlebar Attachment)
Pre-installed Hardware (not shown)
Item # Qty. Hardware Description
12 2 M4 x 8L - Screw
(Upright Cover Attachment)
13 4 M4 x 10L Screw - (Console Attachment)
14 6 #8 x 5/8”L Screw - (Cup Holder Attachment)
15 4 M8 x 15L Bolt- (Mounting Bracket)
16 4 M8 Washer - (Mounting Bracket)
Assembling Your Treadmill
#8 x 5/8”L
(x6)
M4 x 8L
(x2)
M4 x 10L
(x4)
M8 Washer
(x4)
M10 x 45L
(x4)
6mm Allen
Wrench
5mm Allen
Wrench w/
Phillips
M10 Washer
(x4)
M8 x 70L
(x2)
M8x 15L
(x4)
