LifeSpan TR800 - Console Cover and Angle Adjustment

Step 5: Attach the Back Cover Plate
A. Align the back console cover (7) over the back of the console and attach using the 4
screws (H).
Step 6: Lock Console Angle
A. Using the 5 mm Allen wrench tighten the 2 Allen head bolts located at each end
7
H
Securely
Tighten
