Lifetime 1533 - Page 10

10
HARDWARE IDENTIFIER
"!#+"/!2$4/2)-!33%-",9(!2$7!2%#/.4).5%$
Hardware shown at 25% of Actual Size
6.625”
(Not actual length)
"!#+"/!2$4/0/,%!33%-",9(!2$7!2%
Hardware shown at Actual Size
!$' (x4)
1/2” x 6.625” Hex Bolt
6 1/2”
(Not actual length)
ABA (x1)
3/8” x 6 1/2” Hex Bolt
AAX (x4)
1/2” Centerlock Nut
ABL (x4)
.69” x .59” Black Spacer
ABP (x4)
1/2” x 3/8” Clear Poly Spacer
ABB (x1)
3/8” Centerlock Nut
APK (x1)
v5"OLT
AOX (x1)
Rim Support Channel
