Lifetime 1533 - Parts List; Hardware List

6
PARTS LIST
HARDWARE LIST
ID Item Description Qty
Pole Assembly Hardware (1066287)
ADS 1/4” x 3/4” Screw 2
AOF 3/8” Plug 2
ANS 1/2” Nylon Plug 2
CIH Domed Countersink Washer 2
Pole to Base Assembly Hardware (1066284)
AAO 5/16” Nylock Nut 2
ABD 5/16” Washer 4
AAE 5/16” x 1” Hex Bolt 2
ABN 1/2” x 1/8” Spacer 2
BTS 1/4” Barrel Nut 1
BZO 1/4” x 3” Shoulder Bolt 1
##, 3/16” Allen Wrench 2
Backboard to Rim Assembly Hardware (1046830)
AAS 1/4” x 2 3/4” Hex Bolt 2
ABS 1/2” x 2 5/16” Galvanized Spacer 2
AAC 5/16” x 1 3/4” Hex Bolt 2
ADQ 5/16” x 1” Screw 2
AAB 1/4” Centerlock Nut 2
ABD 5/16” Washer 4
APK v5"OLT 1
ABK 5/16” Nylock Flange Nut 4
AOX Rim Support Channel 1
ID Item Description Qty
!,( Top Pole 1
!,& Middle Pole 1
!,% Bottom Pole 1
AJK Right Backboard Bracket 1
AJJ ,EFT"ACKBOARD"RACKET 1
AJI Backboard 1
!,8 Rim 1
AKZ Net 1
AKC Extension Arm 4
"$, $UNK,ATCH 1
BDM Inner Guard 1
BDN Outer Guard 1
AJM Base 1
!,) Pole Brace 2
AMU Wheel 2
AJC 1/2” x 15 3/4” Axle 1
AJE 1/2” x 7” Axle 1
AEF Base Plug 2
AMT Warning Sticker (Applied to Middle Pole) 1
