19
BACKBOARD TO RIM ASSEMBLY
SEC
3
Hardware shown at Actual Size
HARDWARE REQUIRED
AAS (x2)
1/4” x 2 3/4” Hex Bolt
ABS (x2)
1/2” x 2 5/16” Galvanized Spacer
ABD (x4)
5/16” Washer
ABK (x4)
5/16” Nylock
Flange Nut
AAB (x2)
v#ENTER
lock Nut
Hardware shown at 25% of Actual Size
APK (x1)
v5"OLT
AOX (x1)
Rim Support Channel
AAC (x2)
5/16” x 1 3/4” Hex Bolt
ADQ (x2)
5/16” x 1” Screw
PARTS REQUIRED
!*) (x1)
Backboard
Part shown at 25% of Actual Size
Part shown at 5% of Actual Size
BDM (x1)
Inner Guard
