Lifetime 3823 User Manual

2
PARTS LIST
ID Part # Description Qty.
AA 1026344 Backboard 1
AB 1018886 Rim 1
AC 502005 Net 1
AD AM01500 Rim Support Channel 1
Rim Hardware (1000480)
RA 300066 5/16” Hex T-Nut 2
RB 300027 5/16” x 1 3/4” Hex Bolt 2
RC 302010 5/16” x 3/4” Hex Bolt 2
RD 302014 5/16” Flat Washer 4
RE BB01400 2” U-Bolt 1
RH 302090 5/16” Nylock Flange Nut 4
RA
Tools and Materials
Required for Assembly
(Not Included)
1. Adjustable Wrench
2. 1/2” Wrenches (2)
3. Needlenose Pliers
HARDWARE IS ACTUAL SIZE
(Unless otherwise indicated)
RC
RD
RH
RB
1. The Backboard can be mounted to Lifetime Products
®
brand pole models.
2. If using an existing pole system that does not have an
extension arm provided, see Page 4.
POLE MOUNT
SAFETY INSTRUCTIONS
Most injuries are caused by misuse and/or not following instructions. Use
caution when using this system.
Owner must ensure that all players know and follow these rules for safe operation of
the system.
To ensure safety, do not attempt to assemble this system without following the
instructions carefully. Check entire box and inside all packing material for parts and/
or additional instruction material. Before beginning assembly, read the instructions
DQGLGHQWLI\SDUWVXVLQJWKHKDUGZDUHLGHQWL¿HUDQGSDUWVOLVWLQWKLVGRFXPHQW
Proper and complete assembly, use and supervision are essential for proper
orientation and to reduce the risk of accident or injury. A high probability of serious
injury exists if this system is not installed, maintained, and operated properly.
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY OR
PROPERTY DAMAGE AND WILL VOID WARRANTY.
• If using a ladder during assembly, use extreme caution.
• Two capable adults are recommended for this operation.
A. Identify and inventory all parts using the checklist boxes on the Parts List. If any parts are missing, call our Customer
Service Department.
% 7HVWÀWDOO%ROWVE\LQVHUWLQJWKHPLQWRWKHLUUHVSHFWLYHKROHV,IQHFHVVDU\FDUHIXOO\VFUDSHDZD\DQ\H[FHVVSRZGHU
coating buildup from inside the holes. Do not scrape away all of the powder coating. Bare metal may rust.
BEFORE BEGINNING ASSEMBLY
!
Mounting Kit Not Included
COPY
