Lifetime 60054 - Hinge & Table Top Assembly Finalization; Secure Assembly to Table Legs; Install Springs

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
16
SEC
CTNX
CTOX
SEC
2.8
)NSERTTWOM6 x 1 x 54 mm Hex-Head Bolts (CSJ)THROUGHTWO1/4” Flat Washers (CTN)THEHOLESINTHE4ABLE,EGSANDTWO
more 1/4” Flat Washers (CTN)3ECURETHE"OLTSWITHTWOM6 x 1 Cap Nuts (AON)BUTDONOTOVERTIGHTEN Repeat this step for the
other side of the Metal Tube.
2
SEC
2.9
5SINGAPAIROFNEEDLENOSEDPLIERSLOOPTHEBOTTOMENDOFASpring (CTO)OVERTHEUPPER"OLTASSHOWN0ULLTHE
UPPERENDOFTHE3PRINGOVERANDINTOTHEGROOVEOFTHE!DJUSTMENT&ORKASSHOWNRepeat this step for the Spring on
the other side of the Metal Tube.
Connect the bottom loop of the Spring
to this Bolt.
Stretch the upper loop of the Spring up and
over the Adjustment Fork and into the groove.
CTO
AONX
CSJX
54 mm
10 mm (x2)
CSJ
CTN
CTN
AON
WARNING
$ONOTOVERTIGHTENTHE#AP.UT
Note: Do not overtighten Nuts
and Bolts.
!
