TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS / INSTRUMENTAL Y HERRAJE REQUERIDOS
9
AMZ
1.3
1.4
• Insert the tabs at the bottom of the Front Panel (AMZ)
into the slots along the front of the Floor Panel.
• Insérer les languettes au bord inférieur du panneau
avant (AMZ) dans les fentes le long du bord avant du
panneau de plancher.
• Insertar la lengüetas al borde inferior del panel
delantero (AMZ) en las ranuras a lo largo del borde
delantero del panel de piso.
• Slide the Panel to the right.
• Faire glisser le panneau à droite.
• Deslizar el panel a la derecha.
X SECTION 1 (CONTINUED) / SECTION 1 (SUITE) / SECCIÓN 1 (CONTINUACIÓN)
