RIGHT DOOR ASSEMBLY / ASSEMBLAGE DE LA PORTE DROITE / ENSAMBLE DE LA PUERTA DERECHA
5
EWI
HARDWARE REQUIRED / QUINCAILLERIE REQUISE / HERRAJE REQUERIDO
Metal Parts / Pièces en métal / Piezas de metal
PARTS REQUIRED / PIÈCES REQUISES / PIEZAS REQUERIDAS
7/16 in/po (≈11 mm) 3/8 in/po (≈10 mm)
BDK (x1)
Plastic Parts / Pièces en plastique / Piezas de plástico
EDW (x1)
CRD (x1)
77 in/po (≈1,96 m)
Top End / Extrémité supérieure / Extremo superior
DHN (x1)
ADW (x1)
BYZ (x2)
BYS (x1)
BYR (x1)
EOZ (x1)
EPA (x1)
AAB (x2)
ACH (x2)
AEB (x2)
CXK (x2)
EPC (x2)
AEE (x3)
CHK (x1)
BBI (x1)
BBH (x1)
DHL
ADZ (x14)
EPH (x1)
TOOLS REQUIRED / OUTILS REQUIS / INSTRUMENTAL REQUERIDO
(Not included—unless indicated otherwise*) / (Non inclus — sauf indication contraire*) / (No incluido, salvo indicación contraria*)
Parts / Pièces / Piezas
