Attach the Handle Assembly to the Outer Tube (ALB) with the hardware
shown. The Lock Tab (APS)XJMMmUJOUPUIFOPUDIPOUIF0VUFS5VCF
SEC
5.3
Note: Make sure that the Inner Channel (AKQ)
has been removed from the Outer Tube before
performing this step.
!
Orient the Height Sticker (AKP) as shown and place it within the grooves
of the Inner Channel (AKQ)-JOFVQUIFCPUUPNFOEPGUIFTUJDLFSXJUIUIF
edge of the Inner Channel.
SEC
5.4
APS
ACY
ACY
ALB
ACYY
Notch
7.5’
10’
AKQ
AKP
Note: Wipe off any grease that may be on the Inner
Channel before attaching the Height Sticker.
!
