4
STEP 1
Note: This step needs to be completed no
matter which Option is used.
HA
HF
HD HE
The Tap Bolts (HF)
should be at the outer
edge of the holes.
HE
Tighten the T-Nuts (HA) only
until the Rubber Washers
(HE) begin to bulge.
(2)
(2)
(2)
HH04900E
1/2” Wrenches
(2)
Required for This Page:
HF
HD
HE
HA
If you have Backboard Brackets that come with a U-Bolt, use
Option 1 and the U-Bolt provided with the Brackets. If the
Backboard Brackets and do not have a U-Bolt, use Option 2.
Any Lifetime
®
Pole unit or Mounting Bracket unit will have the
necessary support to follow Options 1.
U-Bolt
Backboard
Brackets
To Next Page
