Required for This Page:
FROM THIS POINT ON FOLLOW THE INSTRUCTIONS PROVIDED WITH THE POLE OR
MOUNTING UNIT.
NOTE: FAILURE TO PROVIDE ADEQUATE SUPPORT BEHIND THE BACKBOARD WILL VOID THE PRODUCT WARRANTY. FOLLOW ALL ASSEMBLY INSTRUCTIONS CAREFULLY.
FA
Electric Drill
(10)
AF
Remove the plastic film from the Backboard.
The lip of the Frame Pad overlaps the front of the Backboard.
AF
AG
FA
FA
Use an electric drill to insert the Screws.
Attach the Bottom Frame Pad (AG) first.
Align the small line in the back of the Bottom Frame Pad with the seam in the Backboard frame.
AF
AG
AB
AB
Rear view
To Next Page
