Lifetime #7525 - Lifter Arm and Gas Spring Assembly; Connecting Lifter Arms to Gas Spring; Securing Assembly Components; Release Pin Installation

7
Required For This Page:
9/16” Wrenches
Scissors/
Wire Cutters/
Pliers
11.2 Tighten the Nut until it is ush
with the Bolt.
11
11.1 Line up the Rear Lifter Arms
(AR) with the Gas Spring (AN).
AR
MH
AN
AR
AR
AC
HD
1017923
HD
(1)
3/4” Wrenches
(1)
Hammer/
Mallet
12
MD
ME
AM
AN
12.1 Use pliers to bend the
Cotter Pin (MD) as shown
above.
13
13.1 Tighten the Nut until it is ush
with the Bolt.
14
HA
HC
AC
MO
HB
AN
MD
ME
14.1 Slide the Release Pin (HB)
through the oval holes of the clevis
at the end of the Gas Spring (AN).
15
15.1 The Release Pin (HB)
should t into the channels in the
Trigger (AD).
HA
AD
AC
HC
16
16.1 Tighten the Nut (HC)
until it is ush with the Bolt.
HD9185
AD
AC
HB
HA
(2)
MO
(2)
*(Not actual
size)
MD
ME
(1)*
(1)*
HB
HC
(2)
(1)
1/2” Wrenches
MH
