HANDLE ASSEMBLY
PARTS REQUIRED
SEC
5
Parts shown at 10% of Actual Size
AKQX
Inner Channel
ALBX
Outer Tube
Parts shown at 25% of Actual Size
AKIX
Handle
!*3X
Channel Stop
!*9X
Spring
AMNX
Trigger
TOOLS REQUIRED
Phillips Screwdriver
1/2” Wrench X v7RENCHX
AKPX
(EIGHT3TICKER
9/16” Wrench X
