TOOLS AND HARDWARE REQUIRED
X SECTION 3 (CONTINUED)
• Attach a Slide Rail (CRQ) to the Slide Ladder in the position shown. Repeat this step for the other Slide Rail.
3.1
BTS (x4)
DSA (x4)
DSA
DSA
BTS
BTS
CRQ
!
• Do not completely tighten the hardware until instructed later in the assembly.
