TOOLS AND HARDWARE REQUIRED
X SECTION 3 (CONTINUED)
6
3.2
3/16 in/po (≈5 mm)
(2)
• Secure the Deck Support (CRU) to the Slide Rails using the hardware indicated. Tighten this hardware and the
hardware from Sec 3.1.
• Place the Slide Deck (BEO) onto the Deck Support and secure with the hardware indicated.
3.3
BTS (x4)
DXY (x4)
CVZ (x4)
(1)
DXY
DXY
BTS
BTS
CRU
CVZ
CVZ
CVZ
CVZ
!
• Tighten all hardware now.
DXY
BTS
BEO
DXY
BTS
