Lifetime 90240 - Page 21

27
TOOLS AND HARDWARE REQUIRED
X SECTION 3 (CONTINUED)
6
3.4
• Attach the Slide (BEK) to the Deck (BEO) in the location indicated with the hardware indicated.
3/16 in/po (≈5 mm)
(2)
ARM (x3)
ARL (x6)
ARX (x3)
(1)
Top View
Bottom View
ARX
ARX
ARX
ARL
ARL
ARL
ARL
ARL
ARL
ARM
ARM
ARM
CAUTION
• Slide can get hot in direct sunlight. It is not recommended that a slide be installed facing south.
5/16 in/po (≈10 mm)
(1)
(1)
1/2 in/po (≈13 mm)
(2)
