Lifetime 90240 - Page 63

65
TOOLS AND HARDWARE REQUIRED
X SECTION 9 (CONTINUED)
6
9.3
• Attach the Binocular Bracket (BZV) to the Climbing Wall Deck Tube (CBW) and secure with the hardware shown. Attach
the Binoculars (CCD) to the Bracket with the hardware shown.
3/16 in/po (≈5 mm)
(1)
1/2 in/po (≈13 mm)
(1)
ARM (x1)
BRL (x2)
DXY (x1)
ARU (x1)
BTS (x1)
CBW
DXY
BTS
ARU
BRL
BRL
BZV
!
• Do not overtighten the hardware. The Binoculars will not be able to rotate.
ARM
CCD
