Lifetime 90269 - POLE ASSEMBLY STEPS; Align and Seat Pole Sections (Steps 1.4, 1.5)

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
10
SEC
SEC
1.4
SEC
1.5
4USJLFUIFCPUUPNFOEPGUIF1PMFmSNMZmWFUP
TJYUJNFT*GUIFMiddle PoleEPFTOPUDPNQMFUFMZ
DPWFSUIFTMPUPOUIFBottom PoleBGUFSTFBUJOHDO
NOT COMPLETE ASSEMBLY$BMM$VTUPNFS4FSWJDF
ALF
ALE
ADS
Hole
Slot
ADSY
ALF
ALH
5-6 times
Scrap Wood or
Cardboard
ALE
*THIS STEP CANNOT BE REVERSED*
WARNING
The Poles must be seated together! Even if the Poles cover
the slots before seating, they must be struck on a hard
surface fi ve to six times! Failure to seat the Poles correctly
could allow the Poles to separate during use, which could
lead to serious personal injuries or property damage.
1
Note: Do not hit your feet with the Pole sections, as
serious injury could occur.
!
