7
TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS / INSTRUMENTAL Y HERRAJE REQUERIDOS
SECTION 1 (CONTINUED) / SECTION 1 (SUITE) / SECCIÓN 1 (CONTINUACIÓN)
• Secure the pole bracket (ALL) to the middle pole (ALF) with the hardware as shown.
• Attachez le support de poteau (ALL) au poteau du milieu (ALF) à l’aide de la quincaillerie indiquée.
• Sujete el soporte de poste (ALL) al poste intermedio (ALF) usando el herraje indicado.
1.1
ALF
ABE
ABR
Warning sticker
Autocollant d’avertissement
Autoadhesivo de advertencia
AAF
Large holes
Grands trous
Agujeros grandes
Small holes
Petits trous
Agujeros pequeños
AAF (x2)
ABE (x2)
ABR (x2)
9/16”
(≈14 mm) (x2)
ABB (x2)
ABB
ALL
