2
1182656 C
11/17/2017
• Indicates the parts to be used for a section.
• Indicates special heed should be taken when reading.
• Indicates the hardware to be used for a section.
• Indicates the tools to be used for a section.
• Indicates no hardware required for a specifi c page.
• Indicates no parts required for a specifi c section.
• Indicates to use/not to use an electric drill for a specifi c step.
ICON LEGEND
• Indicates the use of a Centerlock Nut. A Nut with this marking will require some effort to tighten.
This hardware was designed with this feature in order to prevent loosening later.
