8 channels mode
Channel Value Function
1 0-255 RED 0% - 100%
2 0-255 GREEN 0% - 100%
3 0-255 BLUE 0% - 100%
4 0-255 WHITE 0% - 100%
5 0-255 AMBER 0% - 100%
6 0-255 UV 0% - 100%
7 0-255 MASTER DIMMER 0% - 100%
8 COLOR MACROS
PLEASE REFER TO COLOR MACROS TABLE
NOTE: Channel 1, 2, 3, 4, 5 and 6 will not work, when Channel 8 is being used.
• : 9 channels mode
Channel Value Function
1 0-255 RED 0% - 100%
2 0-255 GREEN 0% - 100%
3 0-255 BLUE 0% - 100%
4 0-255 WHITE 0% - 100%
5 0-255 AMBER 0% - 100%
6 0-255 UV 0% - 100%
7 0-255 MASTER DIMMER 0% - 100%
0-15 STROBING OFF 8
16-255 STROBING SLOW - FAST
9 COLOR MACROS
PLEASE REFER TO COLOR MACROS TABLE
NOTE: Channel 1, 2, 3, 4, 5 and 6 will not work, when Channel 9 is being used.
Colors macros table as below:
0-3=Off 64-67=B+W 128-131=G+B+W 192-195=R+B+W+A
4-7=Red 68-71=B+A 132-135=G+B+A 196-199=R+B+W+UV
8-11=Green 72-75=B+UV 136-139=G+B+UV 200-203=R+B+A+UV
12-15=Blue 76-79=W+A 140-143=G+W+A 204-207=R+W+A+UV
16-19=White 80-83=W+UV 144-147=G+W+UV 208-211=G+B+W+A
20-23=Amber 84-87=A+UV 148-151=G+A+UV 212-215=G+B+W+UV
24-27=UV 88-91=R+G+B 152-155=B+W+A 216-219=G+B+A+UV
28-31=R+G 92-95=R+G+W 156-159=B+W+UV 220-223=G+W+A+UV
32-35=R+B 96-99=R+G+A 160-163=B+A+UV 224-227=B+W+A+UV
36-39=R+W 100-103=R+G+UV 164-167=W+A+UV 228-231=R+G+B+W+A
40-43=R+A 104-107=R+B+W 168-171=R+G+B+W 232-235=R+G+B+W+UV
44-47=R+UV 108-111=R+B+A 172-175=R+G+B+A 236-239=R+G+B+A+UV
48-51=G+B 112-115=R+B+UV 176-179=R+G+B+UV 240-243=R+G+W+A+UV
52-55=G+W 116-119=R+W+A 180-183=R+G+W+A 244-247=R+B+W+A=UV
56-59=G+A 120-123=R+W+UV
