LEGO PICKUP TRUCK 10290 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
10
Legend
DISCONNECT
CONNECT /
RECONNECT
TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect the
White 30cm Bit Light
to the ‘OUT’ port on
the NC Push Board
White 30cm Bit Light
Trans Clear Round Plate
2x2 w/ Rounded Bottom
NC Push Board
15cm Connecting Cable
