LEGO PICKUP TRUCK 10290 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
11
Legend
DISCONNECT
CONNECT /
RECONNECT
TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect the
15cm Connecting
Cable to the ‘OUT’
port on the NC Push
Board
Ensure the
NC Push Board is
placed in the same
position as shown
