BTS DYNAMITE 21339 LIGHT KIT INSTALL GUIDE
13
If you experience any issues with the
lights not working and suspect an issue
with a component, please try a dierent
port on the expansion board to verify
where the fault lies (with the light or
expansion board). To correct any issues
with expansion board ports, please view
the section addressing expansion board
issues in our troubleshooting section.
!
!
8-Port Expansion Board
13
IR Control Board w/ Receiver Speaker
NOTE
Connect the Speaker to the
‘Audio’ Port on the IR Control
Board
To Next Page
